Switch Industrial 4-puertos PoE AW-IHT-0500 Ampliar

AW-IHT-0500 Switch Industrial 4-puertos PoE

Industrial PoE Switch AW-IHT-0500 4xFE PoE + 1xFE

Más detalles



IP Camera Compatibility

Video ResolutionMegapixel/D1/VGA
Video CompressionMJPEG / MPEG-4 / H.264 / H.265


Fast Ethernet (RJ45)5


IEEE 802.3 10-BASE-T (Ethernet)Supported
IEEE 802.3u 100-BASE-TX (Fast Ethernet)Supported
IEEE 802.3x Flow Control(Full-Duplex Flow Control)Supported
IEEE 802.3af Power over EthernetSupported
IEEE 802.3at Power over Ethernet PlusSupported

Ethernet Performance

MAC Address1 K
Buffer Memory128 KB
Transmission MethodStore and Forward
Backplane1 Gbps
Auto-MDI/MDI-X, Auto-NegotiationSupported

Filtering/Forwarding Rates

10Mbps14,880 pps
100Mbps148,000 pps

Transmission Media

10Base TCat. 3, 4, 5 UTP/STP
100Base TXCat. 5, 5e UTP/STP

PoE Function

Number of PoE Out Ports4
Max. PoE Output Power/per Port30W
802.3at/af Standard CompatibleYes
Over Current ProtectionSupported
Circuit Shorting ProtectionSupported
Total PoE Power Budget120W
Power Pin Assignment1/2(+), 3/6(-)
PoE PD Auto DetectionYes


LED IndicatorsPower, Relay, LAN, PoE
Power InputRedundant Dual 44V-56VDC Power Input Removable Terminal Block
Power Consumption126W
Alarm Relay ContactRelay outputs with current carrying capacity of 1 A @ 24VDC
HousingRugged Metal, IP30 Protection
InstallationDIN-rail Mounting and Wall Mounting
Dimensions142 (L) x 105 (W) x 36.2 (H) mm
Weight0.48 kg
Operating Temperature-40°C ~ 75°C
Storage Temperature-40°C ~ 85°C
  • Operating: 5~95% (Non-condensing)
  • Storage: 5~95% (Non-condensing
Safety CertificationsCE, C-Tick, FCC, VCCI, LVD
Stability Testing
  • EN55022/24
  • EN50155
  • EN55011
  • EN50121-3-2
  • EN50121-4
  • EN 50155 / EN 60068-2-6
  • EN 50155 / EN 60068-2-27
  • EN 50155 / EN 60068-2-32


Included AccessoriesQIG, Terminal Block, DIN-rail Brackets, Wall Mount Kit
