AP-FXC-0100 Ampliar

Extensor Poe 1-puerto AP-FXC-0100

PoE Extender AP-FXC-0100 1-Port Indoor FE

Más detalles



PoE Extension

Extension DistanceMax. 300 M (No Local Power Required)*
PoE Output12-48 W
BandwidthMax. 100 Mbps

IP Camera Compatibility

Video ResolutionMegapixel/D1/VGA
Video CompressionMJPEG / MPEG-4 / H.264 / H.265
Compatible Camera ListVIVOTEK Network Cameras** (FD8381-EV, IB8381-E, FE8181/81V, FE8391 excluded)


Fast Ethernet (RJ45)2


IEEE 802.3 10-BASE-T (Ethernet)Supported
IEEE 802.3u 100-BASE-TX (Fast Ethernet)Supported
IEEE 802.3x Flow Control(Full-Duplex Flow Control)Supported
IEEE 802.3af Power over EthernetSupported
IEEE 802.3at Power over Ethernet PlusSupported

Ethernet Performance

MAC Address2 K
Buffer Memory48 KB
Transmission MethodStore and Forward
Backplane1.0 Gbps
Auto-MDI/MDI-X, Auto-NegotiationSupported

Filtering/Forwarding Rates

10Mbps14,880 pps
100Mbps148,000 pps

Transmission Media

10Base TCat. 3, 4, 5 UTP/STP
100Base TXCat. 5, 5e UTP/STP

PoE Function

PSE PoE Fast Ethernet (RJ45)1
PD PoE Fast Ethernet (RJ45)1
Power over Ethernet Output Compatible 802.3at/af PassivePin Assignment and Polarity: 4/5 (+), 7/8 (-)Output Power Voltage: 45-55VDC
Power over Ethernet Intput Compatible 802.3at/af Passive & StandardSupports Alternatives Mode A or Mode B or Mode A+B Input Voltage: 46-57 VDC Max. Input Current: 0.7A/1.4A


LED IndicatorsPower, IN, OUT
Dimensions80 (L) x 52 (W) x 23 (H) mm
Weight0.16 kg
Operating Temperature0°C ~ 50°C (32°F ~ 122°F)
Storage Temperature-20°C ~ 70°C (-4°F ~ 158°F)
  • Operating: 10~90% (Non-condensing)
  • Storage: 10~90% (Non-condensing)
Safety CertificationsCE, C-Tick, FCC, VCCI


Included AccessoriesQIG, Screw
