Lente | f=4.09 mm F 2.0 Board lens Fixed |
Tiempo de obturacion | 1/5 ~ 1/15,000 sec. |
Sensor de imagen | 1/4" CMOS in VGA Resolution |
Iluminacion minima | 0.4 Lux / F2.0 ( Color ) |
Video | Compression: MJPEG & MPEG-4 Streaming: MPEG-4 streaming over UDP, TCP, HTTP or HTTPS MPEG-4 multicast streaming Supports 3GPP mobile surveillance Frame rates: MPEG-4: Up to 30/25 fps at 640x480 MJPEG: Up to 30/25 fps at 640x480 |
Configuración de imagen | Adjustable image size, quality, and bit rate Time stamp and text caption overlay Flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance and exposure control AGC AWB AEC Supports privacy masks |
Audio | Compression GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps Interface: Built-in microphone Supports audio mute |
Redes | 10/100 Mbps Ethernet, RJ-45 Built-in 802.11 b/g WLAN Protocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS |
Alarma y gestion de eventos | Triple-window video motion detection 1 D/I & 1 D/O for external sensor and alarm Event notification using HTTP, SMTP, FTP Local recording of MP4 files |
Seguridad | Multi-level user access with password protection IP address filtering Wireless: WEP, WPA-PSK, WPA2 |
Usuarios | Live viewing for up to 10 clients |
Dimensiones | Depth: 26.9mm Width: 86.7mm Height: 87.6mm |
Peso | Net: 122 g |
Indicador LED | System power and status indicator System activity and network link indicator |
Energia | 5V DC Power consumption: Max. 6.6 W |
Aprovaciones | CE FCC LVD VCCI |
Entornos operativos | Temperature: 0 ~ 40 °C (32 ~ 104 °F) Humidity: 20% ~ 80% |
Viendo requisitos del sistema | OS: Microsoft Windows 2000 / XP / Vista Browser: Mozilla Firefox Browser: Internet Explorer 7.x or above VLC: 10.5 or above QuickTime: 6.5 or above Cell phone: 3GPP player Real Player 10.5 or above |
Gestion de instalación y mantenimiento | Installation Wizard 2 ST7501 32-channel recording software Supports firmware upgrade |
Aplicaciones | SDK available for application development and system integration |
Garantia | 24 Months |
