System InformationCPU | - Multimedia SoC (System-on-Chip)
| Flash | | RAM | |
|
Camera FeaturesImage sensor | | Maximum Resolution | | Lens Type | | Focal Length | | Aperture | - 1.2 ( wide ), 2.1 ( tele )
| Auto-iris | | Field of View | - 29.95° ~ 83.34° (horizontal)
- 22.99° ~ 61.93° (vertical)
- 39.87° ~ 104.52° (diagonal)
| Shutter Time | - 1/5 sec. to 1/40,000 sec.
| Day & Night | - Removable IR-cut filter for day & night function
| Minimum Illumination | - 0.1 Lux @ F1.2, 50 IRE ( Color )
- 0.001 Lux @ F1.2, 50 IRE ( B/W )
| Pan / Tilt / Zoom | - ePTZ
- 16x digital zoom ( 4x on IE plug-in, 4x built-in )
| IR Illuminators | - Built-in IR illuminators, Effective up to 25 meters
- IR LED * 24
| On-board Storage | |
|
VideoCompression | | Maximum Frame Rate | - H.264: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200
- MPEG-4: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200
- MJPEG: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200
| Maximum Streams | | S/N Ratio | | Dynamic Range | | Video Streaming | - Configurable video cropping for bandwidth saving
| Image Settings | - Adjustable image size, quality, and bit rate
- Time stamp and text caption overlay
- Configurable brightness, contrast, saturation, sharpness, white balance and exposure control
- BLC (Backlight compensation)
- Supports privacy masks
- Scheduled profile settings
|
|
AudioAudio Capability | - Audio input / Audio output
| Compression | | Interface | - External microphone input
- External line output
|
|
NetworkUsers | - Live viewing for up to 10 clients
| Protocols | - IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X
| Interface | - 10 Base-T / 100BaseTX Ethernet (RJ-45)
| ONVIF | - Supported, specification available at www.onvif.org
|
|
Intelligent VideoVideo Motion Detection | - Triple-window video motion detection
|
|
Alarm and EventAlarm Triggers | - Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
| Alarm Events | - Event notification using digital output, HTTP, SMTP, FTP and NAS server File upload via HTTP, SMTP, FTP and NAS server
|
|
GeneralConnectors | - RJ-45 cable connector for Network/PoE connection
- Audio input
- Audio output
- DC 12V 24V AC Power input
- Digital input * 1
- Digital output * 2
- RS-485
- SD/SDHC/SDXC card slot
| LED Indicator | - System restore status indicator
| Power input | - 12V DC
- 24V AC
- 802.3af Power-over-Ethernet (Class 3)
| Power consumption | - Max. 5.82 W (DC 12V )
- Max. 8.1 W (AC 24V )
- Max. 7.2 W (PoE )
| Dimensions | | Weight | | Casing | - Weather-proof IP67-rated housing
| Safety Certifications | - CE C-Tick FCC ( Class A ) LVD VCCI
| Operating Temperature | - Operating Temperature: -20 ~ 50 °C (-4 ~ 122 °F )
- Starting Temperature: -20 °C ( -4°F )
| Warranty | |
|
System RequirementsOperating System | - Microsoft Windows 2000 / XP / Vista
| Browser | - Mozilla Firefox 7~10 ( Streaming only )
- Internet Explorer 7.x or 8.x
| Other Players | - VLC: 1.1.11 or above
- QuickTime: 7 or above
|
|
